Technical Parameters

Model							4x2 Tractor		6x4 Tractor
Drive							4×2/2		6×4/2
Steering wheel direction (L or R)							L		L
Market input	Application						Port, short-distance transportation		Port, short-distance transportation, coal, sand and gravel, steel transportation
	GCW (Gross Combination Weight) (T)						≤42		≤49
	Transport distance (km)						——		≤150km
	Endurance mileage (km)						≥180		≥150
	Normal speed (km/h)						60-85		60-80
	Maximum speed (km/h)						≤89		≤89
	24V battery						180AH		180AH
	Road conditions						National highway/provincial highway/factory road		National highway/provincial highway/factory road
Regulations			G.V.W (T)				18		25
			Kerb weight				9500kg		11500kg
			G.C.W (T)				42		49
Chassis width					2.5m		●		●
Wheelbase		4×2/2					4400		——
		6×4/2					——		3850 1400
		Front wheel track					2060mm		2060mm
		Rear wheel track					1840mm		1840mm
		Minimum ground clearance					≥250mm		≥250mm
		Approach / departure angle					17°/ 43°		17°/ 43°
Cab.		2.5m		Low floor	High roof, Standard length		●		●
Electric drive assembly			Brand		TOP GEAR		●		●
					CRRC		○		○
Electric engine assembly	Permanent-magnet synchronous motor		Rated/peak power（kW）				250/360		250/360
			Rated/peak torque (N.m)				≥1600Nm/2500Nm		≥1600Nm/2500Nm
			Drive motor speed range				0-3500rpm		0-3500rpm
			Drive motor working system				S9		S9
			Drive motor load control mode				Speed/torque control		Speed/torque control
Gearbox	Brand: TOP GEAR		Transmission model		4-speed AMT		●		●
	Brand: FAST				6-speed AMT		○		○
Power Battery	Battery type		Lithium Iron Phosphate		8*CATLC1 standard box 282KW.h charging and replacing one		●		●
	Brand		CATL
	Power battery cooling type		Liquid cooling
	Cycle life		≥3000 times
Front axle (self-adjusting arm)		Capacity	6.5T	Brake type	Drum with ABS		●		●
Drive axle (self-adjusting arm)		Single reduction	Lightweight 457 axle (with wheel difference)	Brake type	Drum with ABS		——		●
			435 axle (with wheel difference) 435		Drum with ABS		——		○
			H6A axle		Drum with ABS		●		——
Frame			980/865 No overhanging beam		280×80×8		●		●
Rear axle mudguard					Integral		●		●
					Split		○		○
Suspension		Front	Type		Parabolic spring	2Pcs		●		●
		Rear	Type		Parabolic spring	3 1 Pcs		●		——
					Parabolic spring	3Pcs		——		●
Fifth wheel			Model		50#		●		——
					Reinforced 50#		○		●
					90#		○		○
Tyre			Model		12R22.5		●		●
					295/80R22.5		○		○
					315/80R22.5		○		○
					11.00R20		——		——
					12.00R20		——		○
Rim			Model/material		9.0/steel (315/12R22.5)		●		●
					9.0/Aluminum alloy steel (315/12R22.5)		○		○
					9.0/Front aluminum rim and rear steel rim (315/12R22.5)		○		○
Cab accessories			Driver seat	Type	Luxury air suspension seat (integrated with seat belt and armrest with memory function)		●		●
			Rearview mirror	Type	Luxury manual		●		●
				Type	Luxury electric adjustment (with electric heating)		○		○
			A/C	Type	Automatic		●		●
			Flip open cab	Type	Manual		○		○
				Type	Electro-hydraulic, turning angle＞52°		●		●
			Cab suspension	Type	Pneumatic		○		○
				Type	Spring damping four-point suspension		●		●
			Bumper	SMC (sheet molding compounds) non-metal	2.5m (for low floor 2.5m chassis)		●		●
