Hongyan XinDaKang Euro II 4×2 Tractor Truck
Heavy Duty Truck Manufacturer in China
Offer tractor unit, dump truck, cargo truck, concrete mixer truck, bulk cement truck, tanker truck, etc.
This product has been discontinued and removed from our shelves.
Our 4×2 tractor trucks include Hongyan XinDaKang Euro II tractor truck and Hongyan Tampa Euro III tractor truck. The former adopts specially-designed Hongyan XinDaKang cab and the latter use Hongyan Tampa cab. They all use Φ430mm single plate large diaphragm spring clutch and Fuller 9-speed transmission.
Technical Parameters| Hongyan XinDaKang Euro II 4×2 Tractor Truck | ||
| Model | CQ4183TSG351 | |
| Driving type | 4×2 | |
| Total mass kg | 46000, 43500, 38100 | |
| Tractor curb weight kg | 6920 | |
| Saddle carrying capacity kg | 10885 | |
| Total mass of the trailer kg | 38885,36585 | |
| Wheel base mm | 3500 | |
| Outline dimensions mm | Length | 6071 |
| Width | 2500 | |
| Height | 3652,3592 | |
| Max. speed km/h | 90 | |
| Max. gradeability % | 30, 28, 25 | |
| Fuel consumption under certain conditions L/100km | 40, 38, 35 | |
| Saddle joint face ground clearance mm | Idle load/Full load: 11.00tire 50#saddle:1341/1265;11.00tire 90#saddle:1391/1315 | |
| Saddle front/rear turning radius mm | 1540-2050/1800 | |
| Distance between saddle and balance shaft mm | 560 | |
| Traction pin diameter mm | 50.8 or 88.9 | |
| Engine model | WD615.46,WD615.44,WD615.50 | |
| Engine power kw(Ps) | 266(360), 243(330), 213(290) | |
| Max. torque/speed (N.m/(r/min)) | 1460/1400~1600,1250/1400~1600,1160/1300~1600 | |
| Clutch | Φ430mm single plate large diaphragm spring clutch | |
| Transmission | Fuller 9 | |
| Cab | Hongyan XinDaKang cab | |
| Steering gear | German ZF CQ8111D rotary valve steering gear | |
| Driving axle | Full floating, double reduction with differential, Steyr cast steel driving axle | |
| Tire | 11.00-20,12.00-20,11.00R20,12.00R20 | |
| Emission standard | Euro II | |
SAIC HONGYAN Automotive Co.,Ltd is a tractor truck manufacturer based in China. We specialize in producing various kinds of heavy duty trucks, like dump trucks and cargo trucks. Knowing the importance of product quality, we use advanced IVECO prototype technology, employ highly experienced engineers, and implement strict quality control system. Hence, the quality of our products like tractor unit, dump trucks, cargo trucks is highly guaranteed. As our heavy trucks are both aesthetic and practical, they are widely accepted by customers worldwide.
We welcome you to contact us for more information!
