Medical LED Cold Light Source Module

Medical LED Cold Light Source Module
Medical LED Cold Light Source Module
Medical LED Cold Light Source Module
Medical LED Cold Light Source Module
Medical LED Cold Light Source Module
Medical LED Cold Light Source Module
Medical LED Cold Light Source Module
Medical LED Cold Light Source Module
Medical LED Cold Light Source Module
Request a Quote

This medical LED cold light source is made based on our own technologies. (The watts can be customized based on your demands.)

Features
  • This cold light source is equipped with outstanding imported 80W light, with the light temperature reaching 5700K;
  • It is equipped with a LED screen, through which light brightness can be adjusted;
  • The lifespan reaches 5000 hours, which are ensured by several protection measures to keep the light shining;
  • This light source has a 10 mm port to be connected to other lights for even better light performance;
  • Two protection measures have been adopted for the power and sleep button;
  • The energy cost is relatively small and the camera body will generate little heat during operation (<41°C);
  • The cold light source only makes a noise lower than 55dB;
  • This medical imaging camera is driven by an AC220V power supply and can work in places with the temperature ranging from 5°C to 40°C. It is also equipped with power surge protector with 500V clamping voltage and can avoid harms caused by static electricity, with the protection of contact electricity discharge reaching 8 kV and the air discharge reaching 15 kV;
  • Able to be connected with different endoscope camera in different departments while avoid causing interference to high-frequency electric knife;
Specifications
  • Light type: LED
  • LED power: 80W
  • Luminous flux: 180lm
  • Brightness: ≥5000LX
  • Spectral range: 400~700nm
  • Voltage: AC220V 50HZ
  • Input power: ≤150VA
  • Operation conditions: ambient temperature 5℃~ 40℃, relative humidity 30%~80%, atmospheric pressure 760hpa~1060hpa
  • Storage conditions: ambient temperature -20℃~ 55℃, relative humidity ≤80%, atmospheric pressure 760hpa~1060hpa
  • Light output spot diameter: Ø10mm, single spot
  • Cooling method: air cooling
  • Fuse: F2A250V
  • Rated voltage: AC220V 50HZ
  • Noise: ≤60dB(A)
  • Light intensity control: LCD display button control, 0~100 adjustable
  • Standards: GB9706, YY0505, GB/T14710, CE, ROHS
  • Color temperature: 3000K~7000K, default 5700K
  • CRI: ≥90, default 91
  • IR blocking: ≤6mW/Im, default 3.6mW/Im
  • Red/green radiation ratio: allowable tolerance ±20%, default 54%
  • Blue/green radiation ratio: allowable tolerance ±20%, default 64%
  • Net weight: 4.6kg
  • Dimensions: 380mm×300mm×115mm
