Measuring, Roll and Spool Winding Machine
Request a Quote
With an easy operation and high efficiency, the measuring, roll and spool winding machine is ideal for rolling a variety of narrow fabrics for packing. Packing types include winding on a spo disc and a round tube. Each automatic packing machine can also be linked to more than 10 jacquard loom machines.
Parameters
| Tape width | 0~8cm |
| Tape rolling speed | 0~100m/min |
| Spool diameter | 40cm |
| Power | 0.75kW |
| Machine dimension | 1450×600×1600mm |
Features
- The tape length and number is controlled using an advanced electromagnetic brake and microcomputer swinger, making the machine suitable for tapes in a variety of widths. this machine is suitable for tapes of various width.
- The motor speed and torque are controlled via the foot switch, making operation easy and convenient.
- A mechanical length counter is responsible for the low failure rate.
