DXF25 Hydraulic Check Valve
Request a Quote
- Hydraulic check valve is integrated with throttle valve for better performance at low energy loss.
- Hydraulic valve is small and compact, simplifying installation and maintenance.
Applications
- Grader
- Excavator
- Forklift
- Loader
- Bulldozer
- Hoisting machinery
- Mining machinery
Parameters
| Return pressure (MPa) | Maximum:0.8 |
| Rated flow (L/min) | 300 |
| Check valve opening pressure (MPa) | 0.5 |
| Hydraulic oil | Mineral oil (HL, HLP) in accordance with DIN 51 524 |
| Fluid temperature range (℃) | －20～100 |
| Viscosity range (mm2/s) | 10～380 |
| Fluid cleanliness | Not lower than GB/T 14039-93 level 19/16 or NAS 1638 level 10 |
| Weight (kg) | 6 |
Professional supplier engaged in the R&D, manufacturing, and sales of various hydraulic components
Annual production capacity of 250,000 sets of hydraulic components
Over 30 series and over 200 varieties and specifications to meet the specific needs of our clients
