GLT06 Hydraulic Brake Valve
Request a Quote
- Hydraulic brake valve with a small size is simple to install.
- Integrated max. pressure in braking circuit can be limited.
- Braking pressure is proportional to actuation force.
- Great braking effect with quick response, low hysteresis.
- Power brake valve has a ergonomic designed foot pedal, which ensures good operation comfort.
Applications
- Grader
- Wheel excavator
- Forklift
- Wheel loader
- Excavator/loader
- Hoisting machinery
- Other heavy machines
Parameters
| Rated flow (L/min) | 36 | |
| Inlet pressure (MPa) | Maximum 20 | |
| Return pressure (MPa) | Maximum 0.5 | |
| Braking pressure (MPa) | Maximum 12.5 | |
| Hydraulic oil | Mineral oil (HL, HLP) in accordance with DIN 51 524 | |
| Fluid temperature range (℃) | －20～100 | |
| Viscosity range (mm2/s) | 10～380 | |
| Fluid cleanliness | Not lower than GB/T 14039-2002 level 18/15 or NAS 1638 level 9 | |
| Weight (kg) | Single circuit:2.2 | Double circuit:3.2 |
Professional supplier engaged in the R&D, manufacturing, and sales of various hydraulic components
Annual production capacity of 250,000 sets of hydraulic components
Over 30 series and over 200 varieties and specifications to meet the specific needs of our clients
