Single-arm Milling Machine
DBX30-15F single-arm milling machine is stable in performance, flexible and convenient in operation. It is added with an auxiliary column, which helps significantly enhance the overall rigidity. This product has a vertical milling head which can move toward right or left 30 degrees. Based on the user's requirement, it can be available with right-angle milling head or universal milling head. Therefore, this horizontal milling equipment has a wide application range. In especial, it is extremely suitable for processing the large-scale or complicated special shaped workpiece.
Our milling machine tool applies the X, Y, Z axle reducer. The reducer is controlled by the frequency conversion electric appliance, through which the feeding speed can be freely adjusted. This speed reducer features stable performance, high working efficiency, and convenient maintenance. Consequently, our large sized milling equipment is widely used in the mechanical processing and manufacturing industries. And it is warmly welcomed by most users.
Parameters| Item | Unit | DBX15-08F | DBX30-15F |
| Table Size(L×W) | mm | 1700×800 | 3200×1200 |
| Number of T Slots | T | 4 | 6 |
| Longitudinal Travel | mm | 1500 | 3000 |
| Longitudinal Feeding Speed | Kw | 45-500mm (Frequency Conversion Adjustable) | 45-500mm (Frequency Conversion Adjustable) |
| Motor Power for Longitudinal Feeding | Kw | 3 | 3 |
| Horizontal Milling Head | Kw | 5.5 72-508 (6 shifts, adjustable) | 7.5 75-420(6 shifts, adjustable) |
| Recommended Cutting Diameter | mm | φ150 | 200 |
| Cross Travel of Crossbeam | mm | 800 | 1250 |
| Speed of Transverse Feed | mm | 30-350 (Frequency Conversion Adjustable) | 30-350 (Frequency Conversion Adjustable) |
| Vertical Milling Head | Kw | 5.5(TEM-V5) | 5.5(TEM-V5) |
| Recommended Cutter Diameter | mm | 150 | 150 |
| Automatic Lubricating Power | kw | 0.37 | 0.37 |
| Vertical Lifting Travel | mm | 800(End Milling, Side Milling) | 1500(End Milling, Side Milling) |
| Vertical Lifting Speed | mm | 50-500(Frequency Conversion Adjustable) | 50-500(Frequency Conversion Adjustable) |
| Verticality Between the Column and Cantilever Beam | mm/m | 0.03 | 0.03 |
| Straightness of Longitudinal Feed | mm/m | 0.03 | 0.03 |
| Total Power | kw | 17.35 | 24.82 |
| Weight | T | 6.8 | 18.5 |
