Servo Driven Flexible Pouch Packaging Machine, Continuous Motion
Request a Quote
240SDZ/280SDZ/330SDZ
The servo driven flexible pouch packaging machine is built on a continuous, one-direction motion principle. It offers true production flexibility as different pouch sizes and product specifications can be handled through program adjustment, without complex mechanical changeovers. This allows fast response to changing production needs. The pouch handling machine operates in a continuous motion cycle. All working units move in the same direction throughout the process, eliminating traditional reciprocating movements. This supports smoother operation, higher stability, and improved efficiency at speed.
Features
- Full servo drive system
Each motion axis is powered by an independent servo motor for precise and coordinated control. - Modular functional design
Filling systems can be quickly changed based on product characteristics, supporting different materials and applications. - Smart HMI interface
Operators select the required recipe, and the machine automatically adjusts all parameters. Changeover time is reduced from hours to just minutes.
Specifications
| Model | Pouch size range (W × H) | Max filling volume | Packaging speed | dimensions (L × W × H) | Net Weight |
| | （min）100×180 （max）180×250 | 1000ml | ≤60 packs/min | 3700mm×1560mm×1950mm | 2000kg |
| | （min）120×240 （max）240×320 | 2000ml | ≤45 packs/min | 3800mm×1650mm×1950mm | 2300kg |
| | （min）140×280 （max）280×350 | 2500ml | ≤40 packs/min | 4200mm×1800mm×1950mm | 3200kg |
| | （min）100×180 （max）180×250 | 1000ml | ≤60 packs/min | 3700mm×1560mm×1950mm | 2000kg |
| | （min）120×240 （max）240×320 | 2000ml | ≤45 packs/min | 3800mm×1650mm×1950mm | 2300kg |
| | （min）140×280 （max）280×350 | 2500ml | ≤40 packs/min | 4200mm×1800mm×1950mm | 3200kg |
Optional Functions
Zipper opening
Pouch hole punching
- Sombrero hole (butterfly hole)
- Round hole
- Special-shape punching
- Arc hole / Curved slot hole
- Euro hole
Coding options
- Hot stamp coding
- Inkjet printing
- Laser marking
Sealing patterns
- Grid pattern
- Dotted pattern
- Plain/flat pattern
- Vertical rib pattern
Details
Customer Case Studies
As a contract packer handling multiple formulas, what operational capabilities enhance flexibility?
As a contract packer handling multiple formulas, what operational capabilities enhance flexibility?
Recipe memory functions combined with broad pouch compatibility allow fast changeovers and better adaptation to different materials in contract packaging operations.
