Pouch Powder Packaging Machine
Vertical Form Fill Seal Machines with Auger Weigher for Powdery Products
- Dosing System
- Auger Weigher
- Bags Per Hour
- 300-3600
- Bag Volume
- 2000 to 14000ml
- Bag Size (Length × Width)
- 80-500mm × 60-350mm
This versatile machine is designed to handle precise weighing and filling tasks for a variety of granular and powdered materials, including those with poor flowability.
Ideal applications include milk powder, protein powder, flour, solid beverages, cocoa powder, chicken powder, granulated sugar, food additives, beverage mixes, pharmaceutical ingredients, dyes, and flavoring agents.
- VFFS Packaging Machine
- Screw Feeder
- Auger Filler
- Finished Product Conveyor
- Precise Measurement and Filling: Utilizes an auger filler for accurate measurement and filling of powdered materials.
- High-Performance Servo System: Equipped with a servo-driven system for enhanced precision and stable performance.
- Easy Maintenance: Features a stainless-steel openable hopper for convenient cleaning.
- Safety Compliance: Includes safety protection systems that meet corporate safety management standards.
- Accurate Temperature Control: Intelligent temperature control ensures precise temperature regulation for smooth and attractive sealing.
- Advanced Film Feeding System: Employs a PLC-controlled dual or single film structure with a motorized alignment correction device for precise cutting and sealing.
- User-Friendly Interface: Large touchscreen display enhances control precision, reliability, and smart functionality.
- Comprehensive Automation: Automatically handles processes like measuring, feeding, filling, bag forming, gas filling (or exhausting), date printing, and counting.
- Enhanced Fault Protection: Integrated automatic alarm system minimizes material waste and facilitates timely troubleshooting.
- Versatile Packaging Options: Supports various packaging styles, including back sealing, gusseted bags, linked bags, and punch-hole designs.
Your production process will benefit greatly from this efficient machine, designed to handle weighing, filling, and more. It’s perfectly suited for measuring both free-flowing and non-free-flowing granular or powdered materials, ensuring precision every time.
With a maximum roll film width of 720mm, this equipment can produce granular packaging bags ranging from 60 to 350mm in width and 80 to 500mm in length, achieving speeds of up to 60 bags per minute. Let this reliable solution enhance your productivity. Contact us today to explore how it can meet your packaging needs!
Kinds of Pouches: 3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc
| Model | |
| Film Width | Max.420mm |
| Bag Length | 80-300mm |
| Bag Width | 60-200mm |
| Film Roll Diameter | Max.320mm |
| Packaging Speed | 300-3600bags/hour |
| Bag Volume | 2000ml |
| Film Thickness | 0.04-0.12mm |
| Power Supply | 220V, 50/60Hz, 3kW |
| Machine Dimensions (L×W×H) | 1217×1015×1343mm |
| Optional | Air Filling Device, Gusseting Device |
| Film Material | BOPP/CPP, BOPP/VMCPP, BOPP/PE, PET/VMPET/PE, PET/AL/PE, PET/PET etc. |
| Model | |
| Film Width | Max.520mm |
| Bag Length | 80-350mm |
| Bag Width | 100-250mm |
| Film Roll Diameter | Max.320mm |
| Packaging Speed | 300-3600bags/hour |
| Bag Volume | 4000ml |
| Film Thickness | 0.04-0.12mm |
| Power Supply | 220V, 50/60Hz, 3kW |
| Machine Dimensions (L×W×H) | 1488×1080×1490mm |
| Optional | Air Filling Device, Gusseting Device |
| Film Material | BOPP/CPP, BOPP/VMCPP, BOPP/PE, PET/VMPET/PE, PET/AL/PE, PET/PET etc. |
| Model | |
| Film Width | 150-620mm |
| Bag Length | 100-450mm |
| Bag Width | 65-300mm |
| Film Roll Diameter | Max.320mm |
| Packaging Speed | 300-2700bags/hour |
| Bag Volume | 8000ml |
| Film Thickness | 0.04-0.12mm |
| Power Supply | 220V, 50/60Hz, 3.2kW |
| Machine Dimensions (L×W×H) | 1488×1180×1550mm |
| Optional | Air Filling Device, Gusseting Device |
| Film Material | BOPP/CPP, BOPP/VMCPP, BOPP/PE, PET/VMPET/PE, PET/AL/PE, PET/PET etc. |
| Model | |
| Film Width | 150-720mm |
| Bag Length | 100-500mm |
| Bag Width | 65-350mm |
| Film Roll Diameter | Max.320mm |
| Packaging Speed | 300-2400bags/hour |
| Bag Volume | 14000ml |
| Film Thickness | 0.04-0.12mm |
| Power Supply | 220V, 50/60Hz, 3.5kW |
| Machine Dimensions (L×W×H) | 1780×1350×2050mm |
| Optional | Air Filling Device, Gusseting Device |
| Film Material | BOPP/CPP, BOPP/VMCPP, BOPP/PE, PET/VMPET/PE, PET/AL/PE, PET/PET etc. |
