Cage Mill Crusher

Request a Quote

Website: http://fertilizermachine-en.com/1-2-cage-mill-crusher.html

Fertilizer Crushing Equipment

Cage mill crusher works by using multiple layers of concentric steel cages or crushing rings. As materials enter the crushing machine, they are repeatedly impacted and pulverized by friction between the high-speed rotating cages. This design is highly effective for materials of medium to low hardness.

Versatile crushing
Ideal for medium to fine crushing of materials like coal, gypsum, fertilizer, and limestone.
Uniform output
Produces a consistent, uniform particle size with minimal over-grinding, making it perfect for brittle materials.
Simple maintenance
The straightforward structure makes maintenance easy, but the cage bars are wear parts and need regular replacement.
Applications
The cage mill crusher is well-suited for crushing materials with a higher moisture content.

Specifications

Model	LF600	LF800	LF1000	LF1300	LF1600
Rotation Diameter (mm)	Ø600	Ø800	Ø1000	Ø1300	Ø1600
Input Moisture Content (%)	≤5
Input Size (mm)	≤10	≤20		≤30
Final Size (mm)	≈0.5
Production Capacity (t/h)	3-5	5-8	10-12	12-15	15-20
Power (kW) (Dual Motor)	11/15	18.5/22	30/37	37/45	45/55

The standard shell material is Q235 steel, with an option for custom 304 stainless steel.
When feeding a production line with wet materials or when a finer output is needed, a cage mill crusher is an excellent choice.

On-Site Cases

Indonesia PT.RANDHOETATAH, a 100,000-ton production line uses our LF800 cage mill crusher.

Sichuan Meifeng Chemical Industry Co., Ltd. purchased our LF1000DE cage mill crusher.
