Hammer Mill Crusher

Request a Quote

Website: http://fertilizermachine-en.com/1-3-hammer-mill-crusher.html

Fertilizer Crushing Equipment

A hammer mill crusher consists of a rotor, hammers, liner plates, and a screen plate. Materials are crushed by the high-speed impact of the hammers and the rebound from the liner plates. The final output size is controlled by the screen plate at the bottom.

Applicable materials
Effective for materials of medium to low hardness, such as limestone, coal, gypsum, and various ores.
High crushing ratio
Can achieve a crushing ratio of 10-25mm, allowing for a single pass to a finer particle size.
Easy maintenance
Features a simple structure that's easy to maintain. However, wear parts like the alloy hammers and screen plates require regular replacement.
Adjustable output
The final particle size can be adjusted by changing the gap of the screen plate.

Applications

Hammer mills are used in compound fertilizer production for crushing materials like ammonium phosphate. They are suitable for both coarse and fine particle operations.

Samples of crushed ammonium phosphate powder:

Specifications

Model	CP400	CP600	CP8060	CP800	CP1000	CP1200
Rotation Diameter (mm)	Ø600		Ø800
Center Distance (mm)	400	600	600	800	1000	1200
Rotation Speed (r/min)	1200		1100		1000
Power (kW)	15	22	37	45	55	75
Input Size (mm)	≤100		≤1500		≤200
Final Size (mm)	≈10
Production Capacity (t/h)	10-15	15-20	20-25	25-30	30-40	40-50

The standard shell material is Q235 steel, with customizable options for stainless steel or stainless steel liners for contact surfaces. Hammers are made from alloy steel.
