Servo Driven Three-Color Screen Printing Machine, JS-310UV

Request a Quote

View All: http://packaging-printer.com/1-7-screen-printing-machine.html

Screen printer for round, oval, square, conical and flat containers

The JS-310UV is an advanced screen printing machine powered by servo motors, offering versatility and high precision. This screen printer is equipped with ten-station rotary design enables three-color printing on surfaces with diameters ranging from 15 to 100 mm. Our screen printing press is highly sought after for its ability to handle a variety of shapes and printing requirements.

Specifications

Printing Product Size (Diameter × Length): (15-100mm)×(20-200mm)
Maximum Printing Speed: 55pcs/min
Power Supply: 380V 3phase 50HZ
Compressed Air Pressure: 4-6bar
Power Consumption: 28kW
Machine Dimensions (L×W×H): 2600×2600×1900mm
Weight: 2900kg

Applications

Ideal for the cosmetics packaging industry For printing on lipstick and mascara tubes, and shampoo bottles.
In electronics manufacturing Suitable for printing on electroplated boards.
For medical auxiliary manufacturing Perfect for printing on medical consumables and pharmaceutical products.
In the food packaging sector For printing on food packaging boxes.

Variety of printable shapes

This screen printing machine is capable of printing on round, curved, and flat surfaces, as well as specialized shapes like flat and conical bottles, offering flexibility in screen printing.

Features

Offers flexibility in printing with options for mono, dual, and three-color printing.

Equipped with a UV drying system, catering to different ink drying requirements for diverse products.

This screen printing machine has a ten-station rotary setup to improve efficiency and ensure consistency in prints.

Equipped with servo-driven print heads, enhancing both printing speed and accuracy.

The screen printer includes an advanced feature that ensures it only prints when an object is correctly positioned, preventing any wasted ink or accidental prints. It has an alarm that alerts the operator to any problems with placing or removing items, which helps maintain a smooth printing process

Optional CCD alignment device available to achieve even higher precision in printing tasks.

Can be fitted with a hot stamping device for additional functionality.

Suitable for processing plastic, aluminum, and electroplated materials.
