1500kg Wheel Loader
Recommended application
The loading capacity of the ZL-15F four wheel drive loader is 1500kg, equipped with four cylinder diesel engine and specially designed drive shaft, and thus has strong cross-country and climbing capability, which can be widely used in the construction of highways, mines, brick and tile factories, urban construction, kilns, stone factories, prefabricated cement parts factories and other agricultural engineering as well as medium and small buildings.
The bucket adopts the convenient tailgate design to prevent the materials from falling during work. If need to meet different jobs requirements, a fast connector can also be selected to replace a variety of loader mount attachments to carry out jobs of different functions, such as snow bucket, fork.
- Front bucket
- Replaceable fork
Rated loading weight | 1500kg |
Rated bucket capacity | 0.8m3 |
Rated power | 36.8KW |
Rated speed | 2650rpm |
Bucket width | 1700mm |
Track base | 1400mm |
Wheel base | 1950mm |
Min. turning radius(outside of rear wheels) | 4400mm |
Min. Ground clearance | 270mm |
Dump height fully raised | 2580mm |
Reach fully raised | 860mm |
Lifting time | < 5.0S |
Max. Tilt angle | 30° |
Max. Bucket breakout, lift cylinder | 42KN |
Maximum Speed | 21km/h |
Operating weight | 3500kg |
Overall dimensions (LxWxH) | 4870x1750x2650mm |
Driving mode | Four-wheel full hydraulic drive |
Transmission gear box form | 2 gear hydraulic variable speed changes |
Engine model | XINCHAI 498(EURO III) |
Engine type | In-line arrangement, water cooled, four-stroke diesel engine |
Engine starting mode | Electric |
Brake mode | Four-wheel hydraulic spread-shoed brake |
Warranty | 12 months after received the goods |
Color | According to the requirements of customers |
Tyre type | 12-16.5 wide tyre |
Shipping port | Qingdao port, China |
Packing details | Nude package, 1Unit/20's GP with disassembled cabin , 3Units/40's HQ |
Delivery time | 20 days after confirm the order |
Supply ability | 100 units per month |
- Operating panel
- Seat
- Operating lever
Hongyuan Vehicle has been manufacturing super quality wheel loaders, is offering front end loaders for agricultural and heavy construction industry. By changing the associated implements on the loaders, we can offer a wide range of special purpose loaders, like sugar cane grab loader, log grapple loader, rough terrain forklift truck, snow plow, rock breaker and so on. With rich export experience and quality assurance, we provide custom need farming and construction equipment with competitive prices.
