YKT-Q-4(8) & YTK-Y-4(8) Hot Runner Sequential Controller

YKT-Q-4(8) & YTK-Y-4(8) Hot Runner Sequential Controller
YKT-Q-4(8) & YTK-Y-4(8) Hot Runner Sequential Controller
Request a Quote
Functions
  • Supply voltage: 110VAC—240VAC; Frequency range: 50HZ—60HZ
  • Control mode: manual or automatic mode (selectable)
  • Time control stage: T1(injection valve gate opening), T2 (injection valve gate delayed opening)
  • Time setting range: 0-999.9S
  • Input signal: 220VAC, 110VAC, 24VDC (the output voltage of the injection molding machine) or digital signal (selectable).
  • Output control voltage: 220VAC, 110VAC or 24VDC (selectable)
  • Output control valve: YTT-4(8) pneumatic valve or YKT-Y-4(8) hydraulic valve optional upon request
Technical specifications
Item
Supply voltage 185V-250VAC
Frequency range 50HZ-60HZ
Operating temperature -20 ℃ -60 ℃
Storage temperature -30 ℃ -70 ℃
Fuse 5A, 5mm × 20mm, 1 ‰ sec
Input signal 24VDC or digital signal
Output voltage 12VDC, 24VDC, 110VAC, 220VAC
Output control valve Pneumatic or hydraulic valve
Time control stage T1: valve gate opening; T2: valve gate delayed opening.
Time control accuracy 0.01s
Product gallery
  • YKT-8 L174*W215*H70 mm
  • YKT-Y-8 L235*W260H130mm
