Our economic high rating PP pleated filter cartridge offers a cost-effective solution without compromising efficiency. This pleated filter cartridge is engineered using a polypropylene membrane, combining high flow rates with superior dirt holding capacity.

This pleated filter cartridge is widely applied in pharmaceuticals, electronics, chemicals, and food and beverage processing. Made of polypropylene, it boasts extensive chemical compatibility, enabling filtration of a wide range of acids, alkalis, and solvents.

Materials of Construction
Filter Medium Polypropylene
Drainage Polypropylene
Center Rod/Housing/End Cap Polypropylene
Specifications
Length 5", 10", 20", 30", 40"
Micron Rating 0.2~20μm
Outside Diameter 68.5mm
Steam Disinfection 121℃/30min
Hot Water Sanitization 85℃/30min
Micron Rating 0.1~20μm
Max. Operating Temperature 80℃
Max. Operating Pressure (inside to outside flow) 4bar/21℃
2.4bar/80℃
Filtration Area 0.4~0.7m2
Chemical Compatibility
Acid R Benzene NR Methyl Ethyl Ketone R
Alkali R Toluene NR Methyl Isobutyl Ketone R
Alcohols R Xylene NR Dichloromethane LR
Fat R Aromatic Aldehyde NR Dichloroethane LR
Acetone R Cyclohexanone R Perchlorethylene LR

Note: R (Resistant); NR (Not Recommended); LR (Limited Resistance)

Applications
  • Prefiltration for reverse osmosis systems, seawater desalination, and various process water treatments.
  • Power plant condensate water filtration and hot water recycle.
  • Filtration in bottling water, high-fructose, edible oil, soft drinks, and dairy industries.
  • Petrochemical processes, refineries, paint coatings, diesel, and dye filtration.
  • Raw material, solvent, and water filtration in the biopharmaceutical industry.
  • Microelectronics plant process water filtration.
