TIG-C SERIES TIG Welder
Request a Quote
Welding machine manufacturerSince 1988
TIG-C SERIES TIG Welder, Tungsten Inert Gas Welding
Features
- The TIG-C series TIG welder combines MMA and TIG welding, ensuring an excellent welding performance on any metal.
- This TIG welder uses IGBT technology.
- High output current
- Three protection functions: waterproof, dust resistant, erosion resistant: This design improves interior electrical component working efficiency, and the hand cooling fan reaches 100% to significantly improve the duty cycle.
- Under a 40°C high temperature working environment, the duty cycle reaches more than 60%.
- The TIG400C machine continuous welds Φ 5mm electrodes.
- Both the arc force current and current declining time are freely set.
- This equipment is equipped with a water cooling welding torch.
Parameters
| Model | TIG-160C | TIG-200C | TIG-250C | TIG-315C | TIG-315CI | TIG-400CI |
| Power Voltage(v) | 230 | 230 | 380 | 380 | 380 | 380 |
| Rated Input Power(kva) | 3.2 | 4.5 | 6.3 | 8.8 | 9.8 | 14.3 |
| Input Voltage Frequency(hz) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| No-load Voltage(v) | 56 | 56 | 54 | 54 | 60 | 60 |
| Output Current Range(a) | 10-160 | 10-200 | 20-250 | 20-290 | 10-315 | 15-400 |
| Duty Cycle(%) | 60% | 60% | 60 | 60 | 60 | 60 |
| Efficiency(%) | 85 | 85 | 85 | 85 | 85 | 85 |
| Insulation Class | F | F | F | F | F | F |
| Weight(kg) | 12 | 12 | 15 | 15 | 27.5 | 28 |
| Measurement(mm) | 460*270*345 | 460*270*345 | 585*320*420 | 585*320*420 | 630*370*500 | 630*370*500 |
| Protection Class | IP21s | IP21s | IP21s | IP21s | IP21s | IP21s |
| Usable Electrode(mm) | 1.6-4.0 | 1.6-4.0 | 1.6-5.0 | 1.6-6.0 | 1.6-5.0 | 1.6-6.0 |
| Cod.(no) | 880011 | 880013 | 880023 | 880024 | 880025 | 880026 |
