TIG-M SERIES TIG Welder, Tungsten Inert Gas Welding
Features
- The TIG-M series TIG welder uses MOSFET inverter technology for an advanced electrical circuit design and energy saving performance.
- It features a stable and reliable welding current.
- The TIG welder features an automatic compensation for power voltage fluctuation.
- This equipment uses advanced inverter technology and offers multiple functions.
- This equipment features an easy to start arc, stable welding current, low welding noise and little spatter, as well as a smooth welding appearance.
- It offers a pulse function which is especially useful for welding thin metal plates.
Parameters
| Model | TIG-160M | TIG-200M | WSM-160 | WSM-200 |
| Power Voltage(v) | 230 | 230 | 230 | 230 |
| Rated Input Power(kva) | 3.2 | 4.5 | 3.2 | 4.5 |
| Output Current Range(a) | 20-160 | 20-200 | 20-160 | 20-200 |
| Rated Duty Cycle(%) | 60 | 60 | 60 | 60 |
| Protection Class | IP21s | IP21s | IP21s | IP21s |
| Measurement(mm) | 460*270*345 | 460*270*345 | 525*320*390 | 525*320*390 |
| Weight(kg) | 12 | 12 | 15 | 15 |
| Usable Electrode(mm) | 1.6~4.0 | 1.6-4.0 | 1.6~4.0 | 1.6~4.0 |
| Cod.(no) | 880030 | 880032 | 880033 | 880035 |
