2 Hole Spinning Spinneret for Manufacturing Braid Tube Reinforced Hollow Fiber Membrane
1. Year: 2016
2. Country: Turkey
3. Customer: National Research Center on Membrane Technologies (MEM-TEK)
4. Product: 2 holes braid tube reinforced hollow fiber membrane spinneret
5. Type: UF spinneret
6. Processing type: Braid tube reinforced coating
7. Application: Environment protection, water purification
8. Specification: 2.6/2.3/2.0
9. Manufacturing capability: 2.600±0.002mm, 2.300±0.002mm, 2.000±0.004mm, assembly concentricity 0.003mm.
10. Spinneret material: Stainless steel
11. Applying material: PVDF (Polyvinylidene Fluoride)
12. Customer MEM-TEK purchased our 2 holes braided tube reinforced hollow fiber membrane spinneret. They required that the spinneret material should have good corrosion resistance, the needle that the braided tube passes through needed high strength and reliability, the material PVDF flow between 2 holes was good, and that the hollow fiber membrane concentricity would be up to standard. After 1 year of use, the spinneret displayed good performance and the customer took a photo expressing gratitude for the quality product. When we visited in 2017, they placed an order of higher efficiency 4 holes braid tube reinforced hollow fiber membrane spinneret.
Applicable material
PVDF (Polyvinylidene Fluoride), CA (cellulose acetate),PVC (Polyvinyl chloride), PES (Polyethersulfone), PSF/PSU (Polysulfone), PA (Nylon, Polyamide),PAN (polyacrylonitrile)
Trustech is a leading polymer fiber spinning spinneret manufacturer, by combined with advanced technology of fiber spinning process and equipment from Germany we can fabricate high quality spinneret, we can offer spinnerets used wet spinning, dry spinning, melt spinning for different fiber spinning process users, we have had clients who used our spinnerets to produce hollow fiber membrane for different filtration applications.
