BH1200-830 Roll Forming Machine
Request a Quote
This product has been discontinued and removed from our shelves.

- Frame of machine: Welded structure with beam steel tube of special shape
- Forming of guide feeding: Side roller type
- Forming machine type: Wallboard and chain drive
- Diameter of shaft: ¢80mm
- Link chain: 16A single row
- Motor power of forming machine: Hydraulic motor
- Line speed of forming machine: 8-12m/min
- Steps of forming machine: 10 steps
- Roller material: Superior forged 45# steel
- Thickness of roller chromium coating: 0.05mm
- Pressure: 20Mpa
- Hydraulic station motor power: 7.5kw
- Hydraulic station Oil pump: Gear pump
- Cutting ways: Hydraulic
- Cutting blade: Cr12 with heat treatment, HRC 58º-60º
- Thickness of the coil: 0.7-1.5mm
- Feeding width: 1200mm
- Precision to length: ±2mm
- Frequency converter: Panasonic (Made in Japan)
- Computer system adopt PLC controlling: Panasonic (Made in Japan)
- Machine size: 6500×1400×1500(mm)
- Total Weight: 8T
