Vibrating Sieve/Sifter

Request a Quote

Website: http://fertilizermachine-en.com/4-2-vibrating-sieve-sifter.html

Fertilizer Screening Equipment

Vibrating sieve is widely used in the fertilizer industry to screen and grade granular fertilizers, ensuring uniform particle size and consistent product quality.

Precise separation
By adjusting vibration parameters like amplitude and frequency and selecting the appropriate screen mesh, the vibrating sieve can precisely separate materials by different particle sizes. This meets the strict size requirements of various production processes.
Compact & stable design
The equipment has a small footprint, is easy to operate and maintain, and has high operational stability. Its key components are made from wear- and corrosion-resistant materials, extending the service life and reducing operational costs.
High efficiency
High-frequency vibration effectively prevents material from clogging the screen, which boosts screening efficiency and precision.

Specifications

Model	Screen Surface					Input Particle Size (mm)	Production Capacity (t/h)	Vibration Frequency (beats per minute)	Dual Amplitude (mm)	Power (kW)	Dimensions (L×W×H) (mm)	Weight (kg)
Model	Number of Deck	Area (m²)	Inclination (°)	Mesh Size (mm)	Structure	Input Particle Size (mm)	Production Capacity (t/h)	Vibration Frequency (beats per minute)	Dual Amplitude (mm)	Power (kW)	Dimensions (L×W×H) (mm)	Weight (kg)
ZWS1230	1	3.6	37	10×40	Woven wire mesh	≤60	30-35	1450	3-5	0.85×2	3090×1700×3169	1623
2ZWS1230	2	3.6	33	Upper 4×50 Lower 1.4×50	Woven wire mesh	≤60	30-35	1450	3-5	0.85×2	3301×1680×3300	2300
ZWS1245	1	5.4	37	Upper 4×50 Lower 1.4×50	Woven wire mesh	≤60	45-60	1450	3-5	0.85×3	4350×1660×5066	2631
2ZWS1245	2	5.4	37	Upper 4×50 Lower 1.4×50	Woven wire mesh	≤60	45-60	1450	3-5	0.85×3	4496×1660×5648	3612
ZWS1260	1	7.2	20	4×25	Woven wire mesh	≤60	60-90	1450	3-5	0.85×4	6576×1660×4240	3290
2ZWS1260	2	7.2	37	Upper 4×50 Lower 1.4×50	Woven wire mesh	≤60	60-90	1450	3-5	0.85×4	5678×1660×6156	4532

The body's shell is made of Q235 steel, the screen mesh is made of stainless steel, and the connections are sealed with rubber.

On-Site Cases

Wuxi Pacific Fertilizer Co., Ltd. purchased our 2ZWS1260 vibrating sieve

Yunnan Xinyunfeng purchased 2ZWS1260 vibrating sieve
