Request a Quote

Inspired by the cutting-edge European design, our fluidized tunnel freezer utilizes the latest in fluidized quick-freezing technology, giving you a revolutionary solution for your quick-freezing needs. Our unique four-dimensional airflow technology allows your products to pass through the quick-freezing zone in a suspended state. Surrounded by vertical high-speed upward cold airflow, your products experience rapid individual freezing without sticking. It’s the perfect solution for your quick-freezing needs in the food industry. Our tunnel freezer offers two options for different product requirements: a plastic conveying mesh belt and a stainless steel mesh belt. Our freezing solution is perfect for quick freezing of various foods, including vegetables, fruits, rice, diced meat, and more.

Specifications
Model Size (mm) Power rating Number of fans Output (kg/h) Belt width (mm)
HNL-T1-600 4135x3420x4250 38KW 2 1000 600
HNL-T2-750 5860x3810x4250 56KW 3 2000 750
HNL-T3-900 7000x4320x4250 74KW 4 3000 900
HNL-T4-900 8500x4320x4250 94KW 5 4000 900
Example kidney beans The infeed temperature is 20℃ and the outfeed temperature is -18℃.
Features
  • Stainless steel centrifugal fan: The fan generates vertical high-speed, high-pressure, and low-temperature airflow under the mesh belt for quick and even freezing of products.
  • Unique pulsator: The pulsator regulates the air pressure and airflow frequency above the product belt, gently separating products during the quick-freezing phase, ensuring that they remain intact.
  • Reciprocating vibration: Helps separate wet or sticky products and turns long and thin products for quick freezing.
  • Large windward surface of the evaporator: With a variable blade pitch design, it prolongs the frosting time and ensures the continuity of production.
  • Bypass regulator: Our freezer adjusts the air pressure above the product, ensuring optimal fluidization for efficient freezing.
  • Fully automatic control system and variable frequency: Our freezer steplessly adjusts the running speed of the mesh belt, ensuring stable and efficient production.
  • Open structure design: Our design gives you easy access to the internal equipment area, facilitating quick cleaning and maintenance.
  • CADF air defrosting system: Our evaporator can maintain high-efficiency heat exchange during long-term operation, reducing the amount of refrigerant filling and effectively utilizing the capacity of the quick-freezer.
Applications
  • Quick-frozen pastry
  • Quick-frozen sea food
  • Quick-frozen poultry
  • Quick-frozen vegetables
