PSC Crushing Hammer Hydraulic Valve
Request a Quote
- Crushing hammer hydraulic valve has compact structure and high reliability.
- Easy piping layout design simplifies the installation and maintenance.
- Hydraulic valve is highly integrated.
- Control valve features quick response and strong power.
- Valve module provides desired flow rates regardless of load pressure.
- No pollution caused, low noise created.
Applications
- Excavator/loader
- Mining machinery
Parameters
| Rated pressure (MPa) | 20 |
| Rated flow (L/min) | 160 |
| Solenoid valve rated voltage | DC24V |
| Solenoid valve rated current | 830mA |
| Solenoid valve insulation grade | H (GB11021-89) |
| Hydraulic oil | Mineral oil (HL, HLP) in accordance with DIN 51 524 |
| Fluid temperature range (℃) | －20℃-100℃ |
| Viscosity range (mm2/s) | 10-380 |
| Fluid cleanliness | Not lower than GB/T 14039-93 level 19/16 or NAS 1638 level 10 |
| Weight(kg) | 9.5 |
Professional supplier engaged in the R&D, manufacturing, and sales of various hydraulic components
Annual production capacity of 250,000 sets of hydraulic components
Over 30 series and over 200 varieties and specifications to meet the specific needs of our clients
