YD-S1600

Features
  • Utilizing wide HP industrial printheads, a single printhead can print up to 297mm in width, with a maximum width of up to 885mm.
  • The maximum material width of this printer is up to 1600mm, making it more versatile and suitable for a wide range of application.
  • The single pass printer utilizes belt technology for continuous high-speed printing, and it is adjustable from 1 to 4 color models, with a printing speed of 360-1800 meters per hour.
  • With pagewide design, this single pass printer is suitable for uninterrupted production of products such as folding boxes, cartons, paper boxes, handbags, packaging boxes, courier boxes, various types of A, B, C, E corrugated cardboard, honeycomb cardboard, kraft paper, thin wood board, and all water-absorbent materials.
  • Printing size can be customized according to requirements to meet the needs of different manufacturers for large or small batch production, eliminating the cumbersome plate-making process.
  • Using fast-drying water-based eco-friendly ink, it dries instantly upon printing, providing waterproof and dirt-resistant patterns after printing.
Printing Samples
Specifications
Model YD-S1600
Print width 885mm
Printhead HP pagewide industrial printhead
Resolution 1200x300dpi 1200x600dpi 1200x1200dpi
Print speed 6-30m/min
Print mode One-pass high-speed printing
Ink color C, M, Y, K
Ink type Water-based dye ink / water-based pigment ink
Printhead quantity 3pcs
Max bed size 140mm
Max material width 1600mm
Feeding Belt conveyor
Ink configuration Ink cartridge CMYK
Data interface RJ45 (Gigabit Ethernet Port)
File formats BMP, PDF, EPS, JPEG, TIFF, CDR
Operating system Win10, x64 and above
Voltage 220V/AC (±10%),50Hz, 8.5kW
Weight 1300kg
Dimensions (L x W x H) 4130mmx1755mmx1860mm
Working temperature 0°C~30°C
