Single Pass UV Inkjet Printer

Request a Quote

Website: http://yottaprinters.com/8-1-single-pass-uv-inkjet-printer.html

Features

Utilizing wide HP industrial printheads, a single printhead can print up to 297mm in width, with a maximum width of up to 580mm.
Designed with belt technology for continuous high-speed printing, this UV inkjet printer is adjustable from 1 to 4 color models, with a printing speed of 360-1200 meters per hour.
With pagewide design, this inkjet printer is suitable for uninterrupted printing on folding boxes, cartons, paper boxes, handbags, packaging boxes, courier boxes, various types of A, B, C, E corrugated cardboard, honeycomb cardboard, kraft paper, thin wood board, and all water-absorbent materials.
Printing size can be customized according to requirements to meet the needs of different manufacturers for large or small batch production, eliminating the cumbersome plate-making process.
Using fast-drying water-based eco-friendly ink, it dries instantly upon printing, providing waterproof and dirt-resistant patterns after printing.

Printing Samples

Specifications

Model	YD-S300
Print width	297mm/580mm
Printhead	HP HI-1000 pagewide industrial printhead
Resolution	1200x300dpi 1200x600dpi 1200x1200dpi
Print speed	6-20m/min
Print mode	One-pass high-speed printing
Ink color	C, M, Y, K
Ink type	Water-based environmentally friendly ink pigment
Printhead quantity	1-2pcs
Material thickness	0-200mm
Max bed Size	600mm
Feeding	Belt conveyor
Ink configuration	Ink cartridge CMYK
Data interface	RJ45 (Gigabit Ethernet Port)
File formats	BMP, PDF, EPS, JPEG, TIFF, CDR
Operating system	Win7/Win8/Win10, X64
Voltage	220V/AC(±10%), 50Hz, 1kW
Weight	300kg
Dimensions (L x W x H)	1950mmx1250mmx1500mm
Working temperature	0℃~300℃
