Crawler Excavator, FK480-9
Request a Quote
Basic Information
-
- Total weight
- 48800kg
-
- Standard bucket capacity
- 2.3m³
-
- Rated power
- 254/1800kW/rpm
Performance Parameters
Job Parameters
Shipping Dimensions
Other Parameters
| Engine | Cummins |
| Engine rated power | 254/1800kW/rpm |
| Gradeability | 70% |
| Fuel tank capacity | 650L |
| Digging force (bucket) | 276kN |
| Travel speed | 3.0-4.8km/h |
| Platform rotation speed | 8.6 r/min |
| Max. digging height | 10190mm A |
| Max. digging depth | 7810mm B |
| Max. digging radius | 7550mm C |
| Max. digging radius on ground | 6800mm D |
| Max. dumping height | 4825mm E |
| Min. turning radius | 12025mm F |
| Max. vertical digging depth | 11815mm G |
| Overall length (transport state) | 12180mm A |
| Overall width (transport state) | 3340mm B |
| Overall height (transport state) | 3280mm C |
| Bucket width | 1463mm |
| Sprocket idler center | 4030mm D |
| Track length | 4961mm E |
| Track width | 600mm F |
| Counterweight ground clearance | 1244mm G |
| Min. ground clearance | 530mm H |
| Hydraulic oil tank capacity | 3308mm I |
