This membrane filter cartridge features PTFE membrane media, the non-stick surface of which offers excellent dust release, making pulse cleaning more effective. JDX Technology's imported PTFE membrane is featured by high precision and excellent filtration efficiency, and capable of capturing extremely small particles as fine as 0.03 µm in size. End caps and center core are subjected to protective treatment, and PTFE membrane filter media provides superior chemical resistance, all these factors guarantee a long service life of the filter cartridge.

Applications
  • Welding smoke
  • Shot blasting
  • Pharmaceutical
  • Cement
  • Chemical
  • Food
  • Tobacco
  • Textile (coal-dust stained yarn) and more
Specifications
Model: JH/P 3266

Outer diameter of top end cap (mm): Ø324
Inner diameter of top end cap (mm): Ø213
Outer diameter of bottom end cap (mm): Ø324
Inlet diameter (mm): Ø16
Height (mm): 660
Filtration area: 9.4
Model: JH/P 321000

Outer diameter of top end cap (mm): Ø324
Inner diameter of top end cap (mm): Ø213
Outer diameter of bottom end cap (mm): Ø324
Inlet diameter (mm): Ø16
Height (mm): 1000
Filtration area: 14.2
Model: JH/P 3566

Outer diameter of top end cap (mm): Ø352
Inner diameter of top end cap (mm): Ø241
Outer diameter of bottom end cap (mm): Ø352
Inlet diameter (mm): Ø16
Height (mm): 660
Filtration area: 10
Model: JH/P 351000

Outer diameter of top end cap (mm): Ø352
Inner diameter of top end cap (mm): Ø241
Outer diameter of bottom end cap (mm): Ø352
Inlet diameter (mm): Ø16
Height (mm): 1000
Filtration area: 15.1

* Custom dimensions are also available as per your request.
