Diesel Forklift 4-5 Tonne Manufacturer

Diesel Forklift 4-5 Tonne

Request a Quote

View All: http://yangft-forklift.com/1-2-diesel-forklift.html

K Series

The diesel forklifts have the load capacity of 4 to 5 tons. The standard lifting height is 3 meters and the maximum customized lifting height is 6 meters, the industrial forklifts can be used to transport concrete and large equipment. The forklifts are available with optional China-made or imported engines, such as Isuzu and Mitsubishi engines from Japan.

This forklift truck features a hydraulic steering system, enhancing maneuverability and ease of operation, particularly for mid- to small-capacity forklifts where coordination is essential.

4000-5000 kg

3000 mm

22-24 km/h

2470-3240 mm

Features

Thanks to the hydraulic steering system, the forklift has a small turning radius which makes it convenient, flexible and safe to drive.
A panel at a low position and the wide-vision mast design provide drivers a broader view.
A trustworthy LCD panel and a user-friendly interplay enable driver to better control the forklift.

Applications

Material handling operation in factories, workshops and construction sites

Forklift Truck Components

Engine (Optional)

Encounter reliability with optional advanced engine configurations, featuring renowned brands like ISUZU, Mitsubishi, Kubota, Yanmar, and Euro3/5. These engines deliver efficent performance with eco-conscious and cost-effective benefits. Built for easy maintenance, they’re designed to boost productivity with minimal downtime.

Seat (Optional)

Featuring an OPS system with ergonomic design and multiple adjustable settings, this option minimizes fatigue, ensuring lasting comfort for operators during extended shifts.

Mast (Optional)

Available with 2-3 stage standard or multi-stage full free lift masts, offering extensive customization to meet a variety of operational requirements.

Load-Backrest

Equipped with a load-backrest, designed to prevent cargo from slipping, enhancing safety throughout the operation.

Control System (Optional)

Integrated with a dashboard along with an ergonomically designed steering wheel, throttle, and brake controls, providing operators with safe, convenient, and comfortable handling.

Overhead Guard

Designed for optimal driver safety, this overhead guard can also be customized for increased width and height to meet specific operational needs.

Control Valve

With a smart, streamlined design, this control valve is simple and intuitive to operate and can be customized to meet unique requirements.

Technical Specifications

Model				CPC(D)40	CPC(D)45	CPC(D)50S	CPC(D)50L
Characteristics	Power			Diesel
	Capacity		kg	4000	4500	5000	5000
	Load Centre		mm	500	500	500	600
	Lift Height		mm	3000	3000	3000	3000
	Min. Turning Radius		mm	2470	2620	2800	3240
Performance	Travel Speed	Load	km/h	22	24	22	24
	Lift Speed	Load	mm/s	380	420	460	500
	Max. Gradeability		%	20	20	20
Dimensions	Total Length	With fork	mm	4000	4120		4690
	Total Length	Without fork	mm	2930	3050	3139	3510
	Total Width		mm	1290	1400	1480	1970
	Max. Height		mm	4190	4220	4200	4600
	Mast Height		mm	2130	2370	2270	2450
Chassis	Tyre	Front		710NHS	300-15	300-15-20PR	8.25-15NHS
	Tyre	Rear		660NHS	700-12	7.00-12-12PR	8.25-15NHS
	Wheelbase		mm	1900	1900	2000	2250
	Service Weight	No load	kg	4950	5860	7100	8200
Power	Engine	Model		Quanchai/Xinchai

What are the advantages of diesel forklifts with a load capacity of 4 tons?

Equipped with powerful engines that feature low RPM, this type of diesel forklifts consumes less fuel. With a small turning radius, it can be used in limited space.

What are the common applications of industrial forklifts?

They are widely used to move materials in warehouses, construction sites, ports, waste disposal facilities, logistics centers and railways.
