FXG-1A/2A fully automatic linear capping machine is made up of unscrambler, conveyor, gripping and capping system, motion control system, etc. The automatic capping machine features compact construction, easy operation and adjustment, which is suitable for automatic capping of 1-5L bottles. This is one of the most recently developed machine model by our company. The capping process will be completed during moving the bottles. The normal machine needs to pause when performing capping operation, so that the liquid will not shake out from the bottle to pollute the bottles' body. Therefore, this newly developed automatic capping machine has higher working efficiency in comparison to the normal model.

Main Features
  • The bottle capping machine adopts full-servo control in terms of capping head, including the height of the capping head, capping speed, and capping torque.
  • It adopts multi-axis motion controller control to better achieve a more stable and efficient production.
  • After changing the bottle type for the first time, you can save the parameters including capping head height, capping speed and torque. When you want to use it next time, you can directly call it to automatically generate the stored parameters.
  • According to different production conditions and product characteristics, you can choose to add a cap sorting machine to work with to improve production efficiency.
  • Applicable to food, medicine, daily chemical, pesticide and other industries.
  • According to different packaging materials, you can choose to use different chucks.
Specifications
Type FGX-1A FGX-2A
Capping head number 1 Capping head 2 Capping heads
Capacity ≤3000 bottles/hour ≤5000 bottles/hour
Cap feeding system Cap pick-off system with a precise chute
Pass rate ≥99%
Applicable bottle type Round bottle: ⌀ 50-140mm, height: 230-340mm Flat bottle: length 45-250mm, width45-140mm, height 90-340mm
Cap specification ⌀ 30-65mm, H15-30mm
Air pressure 0.6~0.8MPa
Power supply 380V, 50Hz / 60Hz
Power 2.5kW 3kW
Machine weight 1100kg 1300kg
Machine dimensions 2195×1300×2300mm (L×W×H)
Machine details

The automatic capping machine comes with a modular construction. Each module has the advantages of quick installation and removal, which greatly saves maintenance and repair time.
