DSV-BP Single Head Shrink Sleeve Labeling Machine
Automatic shrink sleeve label applicator for speeds up to 450BPM
DSV-BP single-head shrink sleeve labeling machine operates at a standard speed of 450 BPM/180mm (standard length) and is capable of using PET 30um and PVC 32um shrink film labeling technology, significantly reducing the cost of shrink film materials. It features servo control using Ethernet communication, ensuring the stability of the labeling equipment's operation and resistance to interference. The optional "multi-reel label unwinder" extends label replacement times and enables the production of high-quality packaging.
- Maximum Speed: 450 BPM
- Bottle Outer Diameter: Ø25mm to Ø125mm (based on customer-provided bottle specifications)
- Film Material: PVC / PET / OPS
- Film Thickness: PVC: 0.035mm to 0.08mm, PET: 0.04mm to 0.06mm, OPS: 0.04mm to 0.06mm
- Machine Dimensions (L×W×H): 1090mm×1130mm×3064mm (our company reserves the right to modify the machine's dimensions for equipment optimization)
- Voltage: 3-phase; 220V, 380V, 415V, 440V (according to customer requirements)
- Can be operated with voltage-free I/O control or Ethernet communication with production and packaging lines.
- Equipped with protective covers and a color human-machine interface (HMI) for parameter setting, simplifying the management of production lines.
- Unique knife plate design eliminates the need for changing knife plate within the specified range. If replacement is necessary, it can be done quickly within minutes.
- Utilizes PLC control to enhance labeling accuracy and speed.
- Features servo motion control, uses Ethernet communication, and is less susceptible to interference during the control process.
- Stores up to 100 sets of recipes for quick access.
- Optional UWI-8 multi-reel label unwinder extends label replacement time, improves production efficiency, and saves labor costs.
- Suitable for use when the conveyor belt speed is not constant; the shrink sleeve labeling machine can still accomplish labeling operation when the conveyor belt changes speed without adjusting the bottle photocell sensor.
- Optional connection with sleeve underlapping machine for producing premium packaging.
- Neck Tamper Evident Banding Used for sealing bottle necks, preventing tampering, and maintaining product integrity.
- Full Body Over-The-Cap Sleeve Labeling Labels cover the bottle neck, body, and bottom, commonly used for sauces, condiments, and similar products.
- Full Body Shrink Sleeve Labeling Labels cover from the lower edge of the bottle neck to the bottom, commonly used for juices, coffee, and more.
- Partial Body Shrink Sleeve Labeling Labels are positioned in the center of the bottle body, commonly used for various bottled and canned products.
- Full Body & Underlap Sleeve Labeling Designed for products requiring labeling to the bottom, enhancing product aesthetics and presentation.
The shrink sleeve labeling machine is widely used in various packaging industries, including beverage packaging, dairy packaging, bottled water packaging, pharmaceutical packaging, personal care packaging, and more. It is suitable for bottles or containers of different sizes and shapes, including square, curved, cup-shaped, and unique types of containers.
