Vacuum Meat Tumbler / Meat Massager
The vacuum meat tumbler is widely used in the processing of hams, sausages, poultry products, and beef and lamb items. Under vacuum, the tumbling action allows brine and marinades to be fully absorbed, ensuring uniform binding between meat and seasonings. This significantly improves water retention, enhances tenderness, increases final yield, and extends shelf life.
The machine is constructed entirely from stainless steel with a compact design. Elliptical drum ends maximize internal tumbling space and improve massaging efficiency.
-
- Marinated beef
-
- Marinated chicken breast
-
- Pickled vegetables
-
- Marinated pork belly
Key Parameters
| Model | HK-60 |
| Material | SUS304 stainless steel |
| Drum volume | ≈60 L |
| Capacity | 15-20 kg per batch |
| Power | 0.57 kW |
| Voltage | 220V/ 50Hz |
| Drum speed | 2-16 rpm |
| Vacuum level | –0.06 to –0.08 MPa |
| Weight | ≈90 kg |
| Dimensions (L×W×H) | 920 × 410 × 840 mm |
Features
-
A-type paddles designed with optimized angles to prevent material buildup and avoid damaging the product
-
Curved mixing paddles create forward, backward, and inner circulation for more uniform tumbling
-
Side feeding inlet allows connection to a vacuum pump, reducing manual contact and improving hygiene
-
Heavy-duty nylon support wheels with precise clearances for stable operation and extended service life
