Printer Slotter Die Cutter with Dryer, CZYL-GQ
Request a Quote
Corrugated Cardboard Converting Machines
The computer-controlled high-speed, high-definition printing and die cutting machine with integrated drying is built for precision, efficiency, and reliability. Designed to meet international standards, it combines advanced servo control, stable vacuum feeding, and intelligent management systems to support large-scale, high-quality carton production.
Features
- Modern Industrial Design
Built with a new-generation industrial appearance that meets European and American standards. - Full Servo Drive
Supports non-stop order changes with fast plate replacement for efficient, user-friendly operation and high output. - Stable Printing System
Fixed-top printing with vacuum suction feeding ensures smooth paper transport, excellent registration accuracy, and simple maintenance. - Smart Central Control
Industry-first handheld control panel with real-time data transfer across units, enabling efficient production management and convenient remote maintenance. - Versatile Slotting
Equipped with a three-crease slotting structure, including one 1
1 large-diameter creasing roller, adaptable for different carton styles and order requirements. - Reliable Electronics
Uses a German Siemens system with key electronic components from trusted global brands such as Siemens and Schneider, plus a remote module for easier servicing. - Advanced Production Management
One-click order changes, storage for over 10,000 orders, and ERP system connectivity streamline plant operations.
Specifications
| Model | | | | |
| Max. speed (sheets/min) | 300 | 250 | 180 | 150 |
| Paper feeding accuracy (mm) | ±0.5 | ±0.5 | ±0.5 | ±0.5 |
| Min. sheet size (mm) | 260×500 | 320×600 | 350×600 | 380×600 |
| Max. sheet size (mm) | 850×2000 | 1150×2400 | 1350×2600 | 1550×2800 |
| Skip feeding sheet size (mm) | 1200×2000 | 1400×2400 | 1600×2600 | 1800×2800 |
| Max. printing area (mm) | 820×2000 | 1150×2400 | 1400×2400 | 1550×2800 |
| Printing roller diameter (include plate) (mm) | 304 | 407 | 482 | 536 |
| Printing accuracy (mm) | ±0.5 | ±0.5 | ±0.5 | ±0.5 |
| Printing plate thickness (mm) | 7.2 | 7.2 | 7.2 | 7.2 |
| Max. die cutting size (mm) | 900×2000 | 1200×2400 | 1400×2600 | 1600×2800 |
| Die cutting accuracy (mm) | ±0.5 | ±0.5 | ±0.5 | ±0.5 |
