F Series CO₂ Laser Tube (Laser Machine Accessory) Manufacturer

F Series CO₂ Laser Tube (Laser Machine Accessory)

Request a Quote

View All: http://efrlaser.com/3-co2-laser-tube/200479/index.html

Country of Origin: China
Product Standard: Q/EFR/J 1.1-2012
Certifications: CE certificate, Chinese technical letters patent
Outer Power: 80-170 (W)
Maximum Power: 50-190 (W)

Overview
EFR's F series CO₂ Laser tube is an upgraded laser machine accessory equipped with a German discharge tube that has been galvanized with a catalyst. Its laser power is up to 200W, which is significantly higher than that of traditional laser tubes. This cost-effective classic CO₂ laser tube has a compact size and stable laser power, high-quality laser beam, great beam mode, a small light spot, a fast speed and a service life of up to 6,000 hours.

Parameters
Features
Operating Condition
Package Size
Quality Guarantee

Parameters

Model	Length(mm)	Outer Diameter(mm)	Outer Power(W)	Maximum Power(W)	Operating Current	Catalyst
F08	850±20	￠80±2	40	50	22	Yes
F0	1050±20	￠80±2	50	60	22	Yes
F2	1250±20	￠80±2	80	95	28	Yes
F4	1450±20	￠80±2	100	120	30	Yes
F6	1670±20	￠80±2	130	150	30	Yes
F7	1700±20	￠80±2	140	170	30	Yes
F8	1850±20	￠80±2	150	170	30	Yes
F10	2050±20	￠80±2	170	190	30	Yes

Features

High power: The replacement parts of the upgraded laser cutting machine are galvanized discharge tubes with German catalysts, significantly increasing the power.
Reliable Stability: We carry out strict quality control during the firing process of the CO₂ Laser tube, and ensure they have a guaranteed reliability and stability.
Long Service Life: Due to the galvanization of the catalyst inside and specially treated electrodes, the discharge tube has a better stability, and a long service life of up to 6,000 hours, ensuring long term reliable operations.

Performance and Applications

With a small light spot, stable performance and service life of 6,000 hours, EFR's 200W CO₂ Laser tube can be applied to different laser machining equipment, including laser engraving machines, laser cutting machines, laser marking machines and laser die cutting machines.

We have supplied a number of laser equipment accessories for different laser engraving machine and laser cutting machine manufacturers. As they are popular among customers, the CO₂ Laser tube is widely used in laser cutting, laser engraving, and laser marking in advertising, packaging, craftwork processing, decorative building materials and leather product industries.

Cutting: F6, F8, and F10 CO₂ Laser tubes are suitable for cutting materials in advertising, exhibition, decoration and other industries. These cost-effective glass laser devices can meet different processing requirements.

Engraving: F2 and F4 CO₂ laser tubes have excellent laser engraving performance under pre-ionization conditions. Our laser tubes are capable of high frequency pulse engraving.

Operating Condition

Cooling method: Water cooling
Cooling liquid: clean water
Flow rate: 3-5L/min.
(F2 CO₂ Laser tube has the flow rate of 2-5L/min.)

Standard water temperature: 10℃-40℃
Ambient temperature: 2℃ -40℃
Ambient humidity: 10-60%

Cleaning Tips: When cleaning the window of the carbon dioxide laser tube, please do not use cotton swabs or other wipes as they will significantly affect the output power.

The following methods are provided for cleaning the window
1. When the lens is stained, turn off the laser tube.
2. Use an air dust blower to blow away dust and dirt on the lens.
3. Use a syringe to spray ethanol on the lens.
4. After the ethanol evaporates, turn the laser tube back on.
5. If the above methods do not work effectively, professionals are required, who will use a cotton swab dipped in ethanol to clean the lens in a rotating fashion away from the center, outwards to the edge.

Special Notice
1. Do not use acetone to clean the glass.
2. Do not move the two fastening screws on both ends of the laser tube, otherwise, the output power will decrease, and the laser tube will be scraped.
3. When testing the light spot on organic glass, please keep the organic glass 300mm away from the window.

Safety
As the CO₂ glass laser device generates invisible light, please wear eye protection gear when operating. A safety sign for high voltage is marked on the positive pole.

Storage and Transportation Requirements
When storing and transporting the CO₂ Laser tube, please drain the cooling liquid and cover the tube ends with dustproof plastic bags. For storage, the required environmental temperature is 2-40℃ and the humidity ranges from 10-60%.

Adhesive tapes and sponges should be used to fix the laser tubes and prevent sliding during transport. A 70mm sponge should be use at the end of the window, and a 50mm sponge should be at the end of the fully reflecting mirror.

Package Size

Model	Packing	Dimensions (LWH)(cm)	Net Weight (kg)	Gross Weight (kg)
F2	Single Packing	1453234	2.5	6
F4	Single Packing	1653234	2.8	7
F6	Single Packing	1903234	3.2	8
F7	Single Packing	1913234	3.5	8
F8	Single Packing	2013234	4	8.7
F10	Single Packing	2213234	4.5	9.5

Quality Guarantee

Warranty: 360 days

Within 180 days from ex-factory date on the label, we replace free of charge if the power is less than 80% of rated power while the users operate according to our manual. The replaced laser tube will have same warranty as new ones. The single transportation freight will be afforded by buyer. When the laser tube structure is damaged or changed, we will not be responsible.
From 181st days to the 360th days from ex-factory date on the label, we repair or replace free of charge if the power is less than 75% of rated power while the users operate according to our manual. The replaced or repaired laser tube will have same warranty as the one which buyer purchased first time from us. The single transportation freight will be afforded by buyer. When the laser tube structure is damaged or changed, we will not be responsible.
We are not responsible for damage or problems that occur during the incorrect usage and do not fall in line with the instruction books.
